在現在自動化設備越來越普及的時代，直線導軌的使用會越來越多，而直線導軌運用常見問題也會越來越多，問題都是用來解決的。導軌絲杠廠家就跟朋友們來做一下直線導軌運用常見問題的匯總。

In the era of more and more popular automation equipment, the use of linear guide rail will be more and more, and the common problems in the use of linear guide rail will also be more and more, problems are used to solve. The guide screw manufacturer will work with friends to summarize the common problems in the use of linear guide.

1、運作一段時間之后，可能會發現直線導軌的軌跡有印壓痕，而且滑塊鋼珠開裂，這是什么原因？

1. After operating for a period of time, it may be found that the track of the linear guide rail has imprints, and the steel ball of the slider is cracked. What is the reason?

一般是因為負荷過大，鋼珠離開軌跡，造成鋼珠開裂導致軌跡持續損害。這種情況可以考慮拆換大一級的滑塊，比如20的，更換成25的，或者增加滑塊數量，降低外部荷載，改變安裝辦法下降一側承受能力情況。倘若來源于光滑的原因，可以考慮選用另一種潤滑油，增加潤滑度，減小潤化間距。須經常查看有沒有臟東西進到滑軌，若有臟東西進入就需要改進密封性零配件，或者增加防塵配件。

Generally, the steel ball leaves the track due to excessive load, causing the steel ball to crack and causing continuous damage to the track. In this case, it can be considered to replace the sliding block of a larger level, such as 20, with 25, or increase the number of sliding blocks, reduce the external load, and change the installation method to reduce the bearing capacity of one side. If it comes from the reason of smoothness, another lubricating oil can be considered to increase the lubricating degree and reduce the lubricating distance. Always check whether there is dirt entering the slide rail. If there is dirt entering, it is necessary to improve the sealing parts or add dust prevention parts.

2、滑塊運作一段時間后會出現鋼珠掉出來的情況是為什么？

2. Why does the steel ball fall out after the sliding block operates for a period of time?

鐵銷從珠溝掉下來導致鋼珠損害使用期結束，使鋼件表面有疲倦與負荷過重的情況，或許是由于太多負荷、安裝不正確或只要一側承受力距，這些情況，都有或許導致鋼珠脫落。

The iron pin falls from the bead groove, causing damage to the steel ball and ending the service life, making the steel surface tired and overloaded, perhaps due to too much load, incorrect installation, or as long as one side bears the force distance, which may cause the steel ball to fall off.

3、在滑塊行走一段時間后，發現軸承端蓋與端防污有形變或裂開情況？

3. After the sliding block moves for a period of time, it is found that the bearing end cap and the end anti fouling are deformed or cracked?

安裝辦法的有誤，會讓滑塊與軌道間僅有一側承受力，也或許是遭到外力損害而導致軸承端蓋與端防污的形變或裂開。滑塊內部較差的，能夠變化防污體系，更換別的光滑油脂，加上光滑油量，下降潤化時間距離。安裝時要注意安裝視角的難點，產品裝備的提升，需要由的技能工程師來安裝，防止損害直線導軌滑塊。

If the installation method is wrong, only one side between the sliding block and the rail will bear the force, or it may be damaged by external forces, resulting in deformation or cracking of the bearing end cap and end anti fouling. If the interior of the slider is poor, the anti fouling system can be changed, other smooth grease can be replaced, and with the amount of smooth oil, the lubrication time and distance can be reduced. Attention shall be paid to the difficulties of installation perspective during installation. The improvement of product equipment shall be installed by professional skilled engineers to prevent damage to linear guide sliders.

以上關于直線導軌使用常見問題點反饋匯總，僅僅日常工作中遇到的常見的一部分問題，歡迎朋友們補充，也可聯系小編http://www.306135.com，分享交流！

The feedback summary of the above common problems about the use of linear guide rail is only a part of the common problems encountered in daily work. You are welcome to add, or contact the editor http://www.306135.com , share and exchange!
