線性導軌的使用壽命對機床的使用時間是有很重要的影響的，如果線性導軌出現問題的話不僅維修起來非常麻煩，而且會直接影響機床設備的設備。所以在使用的時候一定要盡量降低其發生狀況的概率，好的方法就是要注意一些使用注意要點。下面導軌絲杠廠家為您分析：

The service life of linear guide rail has a very important impact on the service time of the machine tool. If there is a problem with the linear guide rail, it will not only be very troublesome to maintain, but also directly affect the equipment of the machine tool. So when using it, we must try to reduce the probability of its occurrence. A good way is to pay attention to some key points of use. The following guide screw manufacturer will analyze for you:

當發現線性導軌精度出現問題時我們應及時想到得就是它的滑塊出現了故障，所以檢查滑塊是必須的，但是我們從滑塊的外面是看不出任何名堂的，必須要將其從導軌上面拆下來之后檢查才能找到原因。

When we find that there is a problem with the precision of linear guide rail, we should think in time that its slider is faulty, so it is necessary to check the slider, but we can't see anything from the outside of the slider, so we must remove it from the guide rail and check to find the cause.

那么，作為使用者是不是就可以根據自己的工作經驗和對線性導軌的一知半解的了解就可以自作主張拆卸滑塊呢?這在正規的使用廠家是堅決不允許發生的，因?yàn)閮?nèi)部結構是非常復雜的一個狀態，所以只有的維修人士才可以對其進行拆卸工作。

So, can you, as a user, disassemble the slider at your own discretion based on your own work experience and a little understanding of linear guide rail? This is not allowed to happen in the normal manufacturer, because the internal structure is a very complex state, so only professional maintenance personnel can disassemble it.

其次，精度會嚴重受到灰塵等雜質的影響，而實際的工作環境不可能是無菌室，灰塵的存在是必不可免的。我們能做的就是將灰塵進入滑塊的可能性降低到低程度，所以在線性導軌外面裝上一個保護裝置是很有必要的。通常廠家會用一個尺寸正好的塑料防護罩來阻止灰塵的進入。平時我們不要有事沒事地將塑料防護罩拆下來。

Secondly, the accuracy will be seriously affected by dust and other impurities, and the actual working environment cannot be a sterile room, and the existence of dust is inevitable. What we can do is to reduce the possibility of dust entering the slider to a low level, so it is necessary to install a protective device outside the linear guide rail. Generally, the manufacturer will use a plastic protective cover with the right size to prevent dust from entering. At ordinary times, we should not take down the plastic protective cover.

1、高速運動部環境下;潤滑劑的特性選擇為低扭矩、發熱少的油脂。

1. Under the environment of high-speed moving parts; The lubricant features low torque and less heat.

2、真空環境中;潤滑劑的特性選擇為氟系真空用油脂或潤滑油(蒸汽壓力隨產品不同而有所不同)

2. In vacuum environment; The characteristic of lubricant is fluorine vacuum grease or lubricating oil (steam pressure varies with products)

3、無塵環境中;潤滑劑的特性選擇為粉塵產品量極小的油脂。

3. In a dust-free environment; The lubricant is selected as grease with minimal dust product.

4、在環境受微振動或微行程制約，這些可能造成耐微振磨損腐蝕;此時潤滑劑的特性選擇為易于行程油膜并具有高耐微振磨損腐蝕的油脂。

4. It is subject to micro-vibration or micro-stroke in the environment, which may cause micro-vibration wear and corrosion; At this time, the lubricant is selected as a grease that is easy to travel oil film and has high resistance to micro-vibration wear and corrosion.

5、在環境受諸如工具機等噴濺冷卻液的制約下;此時潤滑劑的特性選擇為油膜強度大，不易乳化或被冷卻劑沖洗掉，高度抗腐蝕且經過精煉的礦物油或合成油。耐水性油脂。

5. The environment is restricted by splashing coolant such as tools and machines; At this time, the lubricant is selected as a refined mineral oil or synthetic oil with high oil film strength, which is not easy to emulsify or be washed off by coolant, and is highly corrosion resistant. Water-resistant grease.

此外線性導軌上面用的密封零件耐溫等級一般都不會超過80℃，所以對于普通的線性導軌要做好溫度設定。更多關于產品的事情就來我們網站http://www.306135.com咨詢了解吧！

In addition, the temperature resistance grade of the sealing parts used on the linear guide rail will generally not exceed 80 ℃, so the temperature setting for the ordinary linear guide rail should be done well. Come to our website for more information about products http://www.306135.com Ask about it!
